Uni-T UT203+ Digital Clamp Multimeter DC AC Current Voltmeter 400-400A
SKU: AR-000197
Rs 8,600
Rs 9,800
Save 12%
In stock
Features Of UT 203 + 400-600A Digital Clamp Meter: • UT203+ with a large LCD display screen and fast ADC / ADC converter, the data display is clear and intuitive, and easy to observe. • UT203 plus Supports full-function with error detection protection, with over-current, over-voltage alarm prompts, you can rest assured that use.
Questions? WhatsApp us →Features Of UT 203 + 400-600A Digital Clamp Meter:
• UT203+ with a large LCD display screen and fast ADC / ADC converter, the data display is clear and intuitive, and easy to observe.
•
UT203 plus Supports full-function with error detection protection, with over-current, over-voltage alarm prompts, you can rest assured that use.
• This multimeter Unit203 plus supports true RMS with high efficiency and real-time measure the RMS of various voltage waveforms.
•
This Meter has a maximum 600V voltage measurement and a high voltage frequency measurement function.
• UT203 plus can be widely used in commercial, industrial, and residential circuit maintenance. It is a great tool for circuit repairmen.
•
Specifications Of UT203+ (upgraded UT203)
Specifications of UT200+ Series 400A/600A Digital Clamp Meters
Specifications
Range
UT201+
UT202+
UT202A+
UT203+
UT204+
AC current (A)
400A
±(2%+10)
±(2%+10)
±(2.5%+5)
600A
±(2%+10)
±(2.5%+5)
AC current frequency (Hz)
50Hz~100Hz
±(1%+5)
±(1%+5)
±(1%+5)
DC current (A)
400A
±(2.5%+5)
600A
±(2.5%+5)
AC voltage (V)
600V
±(0.8%+5)
±(0.8%+5)
±(0.8%+5)
±(0.8%+5)
±(0.8%+5)
AC voltage frequency(Hz)
10Hz~10kHz
±(1%+5)
±(1%+5)
±(1%+5)
10Hz~60kHz
±(0.5%+2)
±(0.5%+2)
DC voltage (A)
600V
±(0.5%+2)
±(0.5%+2)
±(0.5%+2)
±(0.5%+2)
±(0.5%+2)
Resistance (Ω)
40MΩ
±(0.8%+2)
±(0.8%+2)
±(0.8%+2)
60MΩ
±(0.8%+2)
±(0.8%+2)
Capacitance (F)
4mF
±(4%+5)
40mF
±(4%+5)
60mF
±(4%+5)
±(4%+5)
Temperature (℃)
-40℃~1000℃
±(1.5%+5)
±(1.5%+5)
Frequency (Hz)
10Hz~10MHz
±(0.1%+4)
±(0.1%+4)
±(0.1%+4)
Features
Display count
4000
4000
6000
4000
6000
Auto range
√
√
√
√
√
Jaw opening
28mm
28mm
28mm
28mm
28mm
True RMS
√
√
√
√
√
NCV
√
√
√
√
√
Live wire test
√
√
Continuity test
√
√
√
√
√
Diode
√
√
√
√
√
MAX/MIN
√
√
√
√
√
Relative mode
√
√
√
√
Zero mode
√
√
Data hold
√
√
√
√
√
Low battery indication
√
√
√
√
√
Auto power off
√
√
√
√
√
General Characteristics
Power
1.5V battery (R03) x 2
Display
37mm x 25mm
Product color
Red and grey
Product net weight
UT201+/UT202+/UT202A+：248g; UT203+/UT204+:235g
Product size
215mm x 63mm x 36mm
Standard accessories
Batteries, test leads, Themocouple (UT202+/UT204+)
Standard individual packing
Gift box, Carring bag, English manual
Standard quantity per carton
40pcs
Standard carton measurement
485mm x 295mm x 385mm
Standard carton gross weight
UT202A+: 17.8kg; UT203+: 16.8kg; UT201+/202+/204+: 17.3kg
• UT203+ with a large LCD display screen and fast ADC / ADC converter, the data display is clear and intuitive, and easy to observe.
•
UT203 plus Supports full-function with error detection protection, with over-current, over-voltage alarm prompts, you can rest assured that use.
• This multimeter Unit203 plus supports true RMS with high efficiency and real-time measure the RMS of various voltage waveforms.
•
This Meter has a maximum 600V voltage measurement and a high voltage frequency measurement function.
• UT203 plus can be widely used in commercial, industrial, and residential circuit maintenance. It is a great tool for circuit repairmen.
•
Specifications Of UT203+ (upgraded UT203)
Specifications of UT200+ Series 400A/600A Digital Clamp Meters
Specifications
Range
UT201+
UT202+
UT202A+
UT203+
UT204+
AC current (A)
400A
±(2%+10)
±(2%+10)
±(2.5%+5)
600A
±(2%+10)
±(2.5%+5)
AC current frequency (Hz)
50Hz~100Hz
±(1%+5)
±(1%+5)
±(1%+5)
DC current (A)
400A
±(2.5%+5)
600A
±(2.5%+5)
AC voltage (V)
600V
±(0.8%+5)
±(0.8%+5)
±(0.8%+5)
±(0.8%+5)
±(0.8%+5)
AC voltage frequency(Hz)
10Hz~10kHz
±(1%+5)
±(1%+5)
±(1%+5)
10Hz~60kHz
±(0.5%+2)
±(0.5%+2)
DC voltage (A)
600V
±(0.5%+2)
±(0.5%+2)
±(0.5%+2)
±(0.5%+2)
±(0.5%+2)
Resistance (Ω)
40MΩ
±(0.8%+2)
±(0.8%+2)
±(0.8%+2)
60MΩ
±(0.8%+2)
±(0.8%+2)
Capacitance (F)
4mF
±(4%+5)
40mF
±(4%+5)
60mF
±(4%+5)
±(4%+5)
Temperature (℃)
-40℃~1000℃
±(1.5%+5)
±(1.5%+5)
Frequency (Hz)
10Hz~10MHz
±(0.1%+4)
±(0.1%+4)
±(0.1%+4)
Features
Display count
4000
4000
6000
4000
6000
Auto range
√
√
√
√
√
Jaw opening
28mm
28mm
28mm
28mm
28mm
True RMS
√
√
√
√
√
NCV
√
√
√
√
√
Live wire test
√
√
Continuity test
√
√
√
√
√
Diode
√
√
√
√
√
MAX/MIN
√
√
√
√
√
Relative mode
√
√
√
√
Zero mode
√
√
Data hold
√
√
√
√
√
Low battery indication
√
√
√
√
√
Auto power off
√
√
√
√
√
General Characteristics
Power
1.5V battery (R03) x 2
Display
37mm x 25mm
Product color
Red and grey
Product net weight
UT201+/UT202+/UT202A+：248g; UT203+/UT204+:235g
Product size
215mm x 63mm x 36mm
Standard accessories
Batteries, test leads, Themocouple (UT202+/UT204+)
Standard individual packing
Gift box, Carring bag, English manual
Standard quantity per carton
40pcs
Standard carton measurement
485mm x 295mm x 385mm
Standard carton gross weight
UT202A+: 17.8kg; UT203+: 16.8kg; UT201+/202+/204+: 17.3kg
